Powershine Lead-acid Replacement Energy Storage Series

Item No.: GL-1236/12100/12150/24200
It can be used in various power stations, base stations, industrial and commercial enterprises, and home energy storage and backup power supply.
Description

Model: GL-1236

Nominal voltage: 12.8V

Nominal capacity: 36AH

Rated power: 460.8WH

Combination method (S series, P parallel): 4S6P

Battery packs usage: single use

Battery size: 198*166*170

Battery weight: 3.3kg

Standard charging current: 6A

Recommended charging current: ≤30A

Peak current: 100A, 10Sec

Load power: ≤465W

Output terminal: M6

Internal resistance: ≤70mΩ

Warranty period: 24 months


Model: GL-12100

Nominal voltage: 12.8V

Nominal capacity: 100AH

Rated power: 1280WH

Combination method (S series, P parallel): 4S2P

Battery usage: can be used individually in series or in parallel

Battery size: 330*173*220

Battery weight: 12.5kg

Standard charging current: 20A

Recommended charging current: ≤50A

Peak current: 250A, 10Sec

Load power: ≤1280W

Output terminal: M8

Internal resistance: ≤40mΩ

Warranty period: 24 months

Model No.: GL-12150

Nominal voltage: 12.8V

Nominal capacity: 150Ah

Rated power: 2560WH

Combination method (S series, P parallel): 4S1P

Battery pack usage: can be used individually in series or in parallel

Size (mm): 520*240*218

Weight: 22kg

Standard charging current: 40A

Recommended charging current: ≤50A

Peak current: 250A, 10Sec

Load power: ≤128W

Output terminal: M8

Internal resistance: ≤40mΩ

Warranty period: 24 months

Model No.: GL-24200

Nominal voltage: 25.6V

Nominal capacity: 200Ah

Rated power: 5120WH

Combination method (S series, P parallel): 8S1P

Battery packs usage: can be used individually in series or in parallel

Size (mm): 520*269*220

Weight: 45kg

Standard charging current: 40A

Recommended charging current: ≤50A

Peak current: 250A, 10Sec

Load power: ≤1280W

Output terminal: M8

Internal resistance: ≤40mΩ

Warranty period: 24 months
